Detailed Product Description:


To print on whatever you want

In the past 5 years, SkyJet UV Flatbed printer has won the customers’ great favor by the superior performance price ratio and good reputation. With the largest market share in domestic market, SkyJet UV FlatMaster and GlassMaster are imported by the customers from more than 20 countries spread over America, Europe, Asia and Australia for expanding the UV printing business successfully. To meet the customers’ demand of printing on flexible material, “Flat-roll to roll” compatible model is put into market.



 Main Features

Roll to roll and rigid materials holding capability achieves direct printing onto rigid materials with high resolution of 1440dpi by instant UV curing way, and convenience of environmental printing on flexible roll media .



 Application filed

Applying to a variety of materials,like rigid media such as glass,ceramic tile, aluminum sheet, wooden board, billboard, acryl sheet, KT  board, plexiglass, foamboard and corrugated paper,flexible materials including wall paper,glistening film, canvas, carpet, leather, paper, PVC ect.



Technical advantages:

u True Flatbed design adopts a strong 4sectional vacuum table or up-down wheels built-in table to keep media stationary on a flat surface while printing to achieve accurate registration on heavy substrates; heavy duty chassis ensures many years durable time, enabling to hold heavy materials virtually up to 100mm in thickness.

u Unique two ways print function in Y direction realizes printing forward or backward at ease, which makes underlay white and overlay white options easy to switch, X-beam’s return time saved as well.

u Adjustable 6-level UV energy is available to suit different materials to avoid thermal deformation.

u Negative pressure ink supply system controls normal colors and white ink separately and built-in temperature sensor &heater type P.H. keeps fluent and continuous print, no need automatic nozzle cleaning during printing, lots of UV ink saved every year.

u Basic 4 colors, 6 colors, white and varnish configurations are available. White options of underlay white, overlay white, fill white, spot white and under color white achieve wonderful white applications.

u Clear top coating varnish as a separate application is used to increase outdoor life, avoid scratch and to add or reduce gloss.


Specification Data


                     Model

                                                           SKYJET FlatMaster-R

            Head Type

              KM-512-MH/LH

       Max Resolution

                    1440DPI

           Media fixing method

        Flatbed

          Roll to Roll

           Heads Number

         4567

          812

  46

            812

        Speed
(M2/H  )

  720x720dpi

           15m2/h

     25 m2/h

         14 m2/h

        24 m2/h

 720x 1080dpi

           10 m2/h

    19 m2/h

        9 m2/h

          17 m2/h

720x 1440dpi

             8 m2/h

     15 m2/h

         7 m2/h

         13 m2/h

           Color mode

 C, M, Y, K, LC, LM+ White+Varnish

           Max Media Thickness

100mm

           Max Printing Width

2500mm

2030mm

           RIP Software

Caldera

          Power requirement

Single Phase 220V,4700W

    Environment requirement

Temperature:20-28 Humidity: 40%-60%

          Dimension

4650*2150*1550(mm)
